Canon 800D Manual
Canon camera user guide. Canon 800D Manual user guide is aimed to fulfill the needs toward information of both technical or instrumental issue among this digital camera product especially for Canon EOS 800D.
Canon 800D is built around a 24MP sensor that uses Canon's Dual Pixel AF system to offer improved autofocus in live view and video (more on that later). EOS 800D is known as the EOS Rebel T7i in the Americas and in Japan as the EOS Kiss X9i.
It has a body-only MSRP of US$749.99, which is same as Canon EOS 750D, which it replaces. The camera can be purchased as a body-only, as kit with the 18-55mm IS STM lens at US$900, with the new 18-135mm IS USM lens at US$1,300.
When was Canon 800D firstly released to the market?
Canon 800D was announced by Canon on February 14, 2017. Even if it’s already released quite long time ago, but this product is still relevant for nowadays use, especially for you who likes retro camera kind of style.
Canon 800D Specifications
Before to jump into the canon eos 800d manual, here is the technical specification of the product. If you want to know more about the review feel free go to dpreview page at here.
Body type: Mid-size SLR
Body material: Composite
Max resolution: 6000 x 4000
Image ratio w:h: 1:1, 4:3, 3:2, 16:9
Effective pixels: 24 megapixels
Sensor photo detectors: 26 megapixels
Sensor size: APS-C (22.3 x 14.9 mm)
Sensor type: CMOS
Processor: DIGIC 7
Color space: sRGB, Adobe RGB
Color filter array: Primary color filter
ISO: Auto, 100-25600 (expands to 51200)
Boosted ISO (maximum): 51200
White balance presets: 6
Custom white balance: Yes
Image stabilization: No
Uncompressed format: RAW
JPEG quality levels: Fine, normal
File format: JPEG (Exif v2.3)
Autofocus: Contrast Detect (sensor)
Autofocus assist lamp: Yes (flash)
Digital zoom: No
Manual focus: Yes
Number of focus points: 45
Lens mount: Canon EF/EF-S
Focal length multiplier: 1.6×
Articulated LCD: Fully articulated
Screen size: 3″
Screen dots: 1,040,000
Touch screen: Yes
Screen type: TFT LCD
Live view: Yes
Viewfinder type: Optical (pentamirror)
Viewfinder coverage: 95%
Viewfinder magnification: 0.82× (0.51× 35mm equiv.)
Minimum shutter speed: 30 sec
Maximum shutter speed: 1/4000 sec
Exposure modes: Program
Scene modes: Group Photo
Built-in flash: Yes
Flash range: 12.00 m (at ISO 100)
External flash: Yes (via hot shoe)
Flash X sync speed: 1/200 sec
Drive modes: Single
Continuous drive: 6.0 fps
Self-timer: Yes (2 or 10 sec)
Metering modes: Multi
Exposure compensation: ±5 (at 1/3 EV, 1/2 EV steps)
AE Bracketing: ±3 (3 frames at 1/3 EV, 1/2 EV steps)
Format: MPEG-4, H.264
Modes: 1920 x 1080 @ 60p / 60 Mbps, MOV, H.264, Linear PCM
Microphone: Stereo
Speaker: Mono
Storage types: SD/SDHC/SDXC (UHS-I compatible)
USB: USB 2.0 (480 Mbit/sec)
HDMI: Yes
Microphone port: Yes
Headphone port: No
Wireless: Built-In
Wireless notes: Includes Bluetooth LE and NFC
Remote control: Yes (via smartphone or Bluetooth remote)
Environmentally sealed: No
Battery: Battery Pack
Battery description: LP-E17 lithium-ion battery & charger
Battery Life (CIPA): 600
Weight (inc. batteries): 532 g (1.17 lb / 18.77 oz)
Dimensions: 131 x 100 x 76 mm (5.16 x 3.94 x 2.99″)
Orientation sensor: Yes
Timelapse recording: Yes
GPS: Optional
How much the price when Canon EOS 800D firstly released?
In the first release, available since April 2017, the Canon EOS 800D can be purchased for under US$749.99 for the body only, as kit with the 18-55mm IS STM lens at US$900, with the new 18-135mm IS USM lens at US$1,300.
And now, if you’re interested to own this compact digital camera device, you can get it in several online stores by paying $973.77 with 18-55 IS STM Lens Black and about USD708.00 for the used product. This is the worth price for what’s offered by this Canon EOS 800D.
Download Canon 800D Manual User Guide PDF
Feel free to download the Canon 800D manual user guide (PDF File) at below.
